Veolia E-Cell MK-9 EDI Module High-Performance Solution for Ultrapure Water in Water Treatment
Подробная информация о продукте:
| Место происхождения: | КИТАЙ |
| Фирменное наименование: | VEOLIA |
| Сертификация: | CE |
| Номер модели: | MK-9 |
Оплата и доставка Условия:
| Количество мин заказа: | 1 шт |
|---|---|
| Цена: | обсуждаемый |
| Упаковывая детали: | Стандартная экспортная упаковка |
| Время доставки: | 5-8 рабочих дней |
| Условия оплаты: | T/T. |
| Поставка способности: | 60000 единиц в месяц |
|
Подробная информация |
|||
| МК-9 Имя стека:: | MK-9 | Размеры стека MK-9 (см как ширина x высота x глубина):: | 30 x 61 x 74 |
|---|---|---|---|
| MK-9 Stack Total Toplectionable Anions (PPM как CACO3):: | <13 | Проводимость стека MK-9 (μS/см):: | <22 |
| MK-9 Stack PH:: | 4-11 | Температура (° C):: | 4.4-40 |
| Твердость (ppm как caco3):: | <1.0 | Кремнезем (ppm as sio2):: | <1.0 |
| Типичное производство воды (M3 /HR):: | 6.0-10.0 | Восстановление:: | До 97% |
| Напряжение:: | 0–400 VDC | Типичные новые приложения:: | Солнечная фотоэлектрика и зеленый водород |
| Выделять:: | Veolia E-Cell MK-9 модуль EDI, модуль EDI с высоким потоком, надежный дизайн EDI Stack | ||
| Выделить: | Veolia E-Cell MK-9 EDI module,EDI module for ultrapure water,high-performance water treatment EDI module |
||
Характер продукции
The Veolia E-Cell MK-9 EDI Module is a cutting-edge electrodeionization (EDI) solution engineered for high-flow, continuous ultrapure water production in water treatment applications. As a flagship product of Veolia, a global leader in water treatment technology, this module integrates advanced E-Cell technology—succeeding Suez’s industry-proven E-Cell™ design—to deliver exceptional performance. It achieves a maximum water flow rate of 10 m³/h (44 GPM) and produces ultrapure water with resistivity ≥16 MΩ·cm, while removing silica to ≤5 ppb, meeting the strict standards of ultrapure water industries. A key advantage is its zero chemical regeneration feature: it eliminates the need for hazardous acids or caustics, slashing operational costs and reducing environmental impact, a critical benefit for sustainable water treatment operations.
In terms of工艺 (process), the Veolia E-Cell MK-9 EDI Module operates on the EDI principle, using an electric field to drive ions from feedwater through ion-exchange membranes, ensuring continuous purification. It seamlessly integrates with reverse osmosis (RO) systems to polish permeate, enhancing overall water treatment efficiency. Its robust construction supports 24/7 continuous operation, with high resistance to scaling and fouling, even under varying feedwater conditions. It also enables hot-water sanitization up to 85°C, satisfying stringent hygiene requirements in industries like pharmaceuticals.
Product Specifications Table
|
Attribute |
Value |
|
Model Number |
MK-9 |
|
Dimensions (cm, W×H×D) |
30×61×74 |
|
Typical Water Production (m³/h) |
6.0–10.0 |
|
Recovery Rate |
Up to 97% |
|
Conductivity (μS/cm) |
<22 |
|
pH Range |
4–11 |
|
Temperature Range (°C) |
4.4–40 |
|
Hardness (ppm as CaCO₃) |
<1.0 |
|
Silica (ppm as SiO₂) |
<1.0 |
|
Voltage |
0–400 VDC |
|
Inlet Pressure |
6.9 bar (100 psi) |
|
Shipping Weight |
165 kg (364 lbs) |
The Veolia E-Cell MK-9 EDI Module serves diverse ultrapure water industry uses, including power generation (boiler feed water, NOₓ control), semiconductor and microelectronics manufacturing, pharmaceutical/biotech (WFI pre-treatment, USP purified water), solar photovoltaics, green hydrogen production, and laboratory ultrapure water systems. Its core advantages—aside from zero chemical regeneration—include enhanced energy efficiency (optimized hydraulics minimize power use), leak-proof design, simplified system setup (no brine injection/concentrated water circulation), and compatibility with PLC/SCADA systems for real-time monitoring. Certified to CE, RoHS, and ISO 9001/14001 standards, it is backed by Veolia’s global service network, making it a reliable, scalable choice for mid-to-large-scale water treatment needs.
