DuPont XP 77 IG 8 Inch PVDF UF Membrane High-Performance Filtration for Critical Industries
Подробная информация о продукте:
| Место происхождения: | КИТАЙ |
| Фирменное наименование: | Dupont |
| Сертификация: | CE |
| Номер модели: | Integratec ™ XP 77 IG (ранее SFP 2880XP) |
Оплата и доставка Условия:
| Количество мин заказа: | 1 шт |
|---|---|
| Цена: | обсуждаемый |
| Упаковывая детали: | Стандартная экспортная упаковка |
| Время доставки: | 5-8 рабочих дней |
| Условия оплаты: | T/T. |
| Поставка способности: | 60000 единиц в месяц |
|
Подробная информация |
|||
| XP 77 диаметр Ig: | 8 дюймов | Площадь мембраны XP 77 IG XP 77 IG: | 77 м² |
|---|---|---|---|
| XP 77 IG Материал: | PVDF | Диапазон потока на модуль: | 2.0 8,5 м3/ч |
| Номинальный диаметр пор XP 77 IG: | 0,03 мкм | Рабочее давление XP 77 Ig: | 1-5 бар |
| Максимум эксплуатационный TMP этого модуля: | 2.1 бар | MAX эксплуатационный поток воздуха в этом модуле: | 12 нм3/час |
| Naocl (макс.) Этого модуля: | 2000 мг/л | Сертификаты этой модели: | ISO 9001, NSF, CE |
| Приложение: | Фарма и напиток | Преимущества модели: | Высокопроизводительные решения фильтрации |
| Выделять: | Dupont XP 77 UF мембрана, 8 -дюймовая мембрана PVDF, фармацевтическая мембрана UF | ||
Характер продукции
The DuPont XP 77 IG 8 Inch PVDF UF Membrane is a state-of-the-art ultrafiltration solution designed for high-stakes applications in pharmaceuticals, beverages, and industrial water treatment. Crafted by DuPont Water Solutions, this 8-inch membrane features premium polyvinylidene fluoride (PVDF) material, renowned for its exceptional chemical resistance, mechanical strength, and thermal stability—making it a reliable choice for environments demanding uncompromising purity and long-term performance. As a key offering in DuPont’s IntegraTec™ lineup, the DuPont XP 77 IG 8 Inch PVDF UF Membrane sets benchmarks in precision filtration, effectively removing particles, colloids, and microorganisms while maintaining consistent flux rates.
The membrane operates on an outside-in filtration工艺: feed water flows across the outer surface of the hollow fibers, where contaminants as small as 0.03 µm are retained. Purified filtrate then passes through the fiber lumen, ensuring efficient separation without the need for chemical coagulants. Its innovative design allows for easy backwashing and cleaning, minimizing fouling and extending service life—reducing operational downtime and maintenance costs.
Key Specifications of DuPont XP 77 IG 8 Inch PVDF UF Membrane
|
Attribute |
Value |
|
Membrane Material |
Polyvinylidene Fluoride (PVDF) |
|
Diameter |
8 Inch |
|
Effective Membrane Area |
77 m² (829 sq ft) |
|
Max Operating Pressure |
5.0 bar (72.5 psi) |
|
Operating Temperature Range |
1–40°C (34–104°F) |
|
pH Range (Operating) |
2–11 |
|
Nominal Pore Size |
0.03 µm |
The DuPont XP 77 IG 8 Inch PVDF UF Membrane offers standout advantages: 99.99% microorganism removal ensures compliance with pharmaceutical and beverage safety standards; PVDF construction resists harsh cleaning agents, prolonging membrane life; and high flux rates optimize water production efficiency. It is widely used in pharmaceutical water purification, beverage clarification, industrial wastewater reuse, and RO pretreatment. Backed by DuPont’s global technical support, this membrane delivers a cost-effective, sustainable solution for industries prioritizing purity and reliability.
